F523F523
Actuator 16A
MQ00362-d-EN 09/06/2014
The device can be configured in two ways:
- PHYSICAL CONFIGURATION, inserting the configurators in position.
- Configuration via MYHOME_Suite software package, downloadable from
www.homesystems-legrandgroup.com; this mode has the advantage of offering many
more options than the physical configuration.
For a list of the procedures and their meanings, please refer to the instructions in
this sheet and to the "Function Descriptions" help section in the
MYHOME_Suite software package.
Configuration
1.1 Addressing
Address type Virtual configuration (MYHOME_Suite) Physical configuration
Point-to-point Room 0-10 A=1-9
Lighting point 0-15 PL = 1-9
Groups
Group 1 - Group 10=0-255 G=0-9
NOTE 1): In the Master and Master PUL mode you can set an OFF delay of 0-255 seconds (via
MYHOME_Suite) and of 1-4 minutes using the physical configuration. Only for a point-point type
control. With the OFF control the Master actuator deactivates; the Slave actuator deactivates after
the time set with the configurators has elapsed.
Typical function for use in bathrooms without windows where the ON control activates the light
(Master actuator) and the ventilation fan (Slave actuator) at the same time. The OFF control
switches the light off immediately and leaves the fan working for the time set with configurator 1
to 4 in M of the Master actuator as indicated in the table.
1.2 Mode
1.2.1 Lights control
Virtual configuration (MYHOME_Suite) Physical configuration
Function Parameter / setting
Master Actuator Master M=0
Actuator as Slave. Receives a control sent by a Master actuator
with the same address
Slave M=SLA
Pushbutton (ON monostable) ignores Room and General controls Master PUL M=PUL
OFF delay: Master actuator with OFF control delayed on the
corresponding Slave actuator.
1)
0 - 255 M=1 1 minute
M=2 2 minutes
M=3 3 minutes
M=4 4 minutes
To use the "Actuator as a slave with PUL function", to define the load to be controlled
and the "closed/open" state of the relay after a reset, use MYHOME_Suite virtual
configuration.
To use "Phase" (Single, 1, 2 and 3), "Type of load", "Load status upon central unit
enabling" and "AC or DC voltage" use MYHOME_Suite virtual configuration.
1.2.2 Load control command
Virtual configuration (MYHOME_Suite) Physical configuration
Function Parameter / setting
Priority 1-63 P1,P2: 01-63
