350
F523
LED signals according to the status of the actuator in automation and load
control management mode:
Common LED notifications:
Device status LED status
Enabled + ON ORANGE
Enabled + OFF GREEN
Disabled RED
Forced + ON ORANGE flashing 1s/1s on GREEN
Forced + OFF ORANGE flashing 1s/1s
Device status LED status
Installation error (230 Vac not detected) Flashing RED 100 ms/900 ms
Configuration error ORANGE flashing irregularly on GREEN
Not configured ORANGE flashing 128 ms/128 ms on GREEN
Actuator 16A
MQ00362-d-EN 09/06/2014
LED signals according to the status of the actuator in automation mode:
Device status LED status
Load OFF GREEN
Load ON ORANGE
LED signals according to the status of the actuator in load control manage-
ment mode:
Device status LED status
Enabled ORANGE
Forced ORANGE flashing 1s/1s on GREEN
Disabled RED
