HC4672N
L4672N
HS4672N
N4672N
HD4672N
NT4672N
2-module ush-mounted actuator 16A
MQ00363-d-EN 09/06/2014
The device can be configured in two ways:
- PHYSICAL CONFIGURATION, inserting the configurators in position.
- Configuration via MYHOME_Suite software package, downloadable from
www.homesystems-legrandgroup.com; this mode has the advantage of offering many
more options than the physical configuration.
For a list of the procedures and their meanings, please refer to the instructions in
this sheet and to the "Function Descriptions" help section in the
MYHOME_Suite software package.
Configuration
1.1 Addressing
Address type Virtual configuration (MYHOME_Suite) Physical configuration
Point-to-point Room 0-10 A=0-9
Lighting point 0-15 PL = 1-9
Groups
Group 1 - Group 10=0-255 G=0-9
NOTE 1): Only for a point-point type control.
With the OFF control the Master actuator deactivates; the Slave actuator deactivates after the time
set with the configurators has elapsed.
In the Off delayed mode, the master sends the Off command after a period of time set using the
1 - 4 configurator connected to M.
1.2 Mode
1.2.1 Automation
Virtual configuration (MYHOME_Suite) Physical configuration
Function Parameter / setting
Master Actuator - Cyclical ON/OFF Master M=0
Actuator as Slave. Receives a control sent by a Master actuator
with the same address
Slave M=SLA
Pushbutton (ON monostable) ignores Room and General controls Master PUL
OFF Delay = 0
M=PUL
Master Actuator with OFF control delayed on the corresponding
Slave actuator.
1)
Master PUL
OFF Delay = 1 - 255
M=1 1 minute
M=2 2 minutes
M=3 3 minutes
M=4 4 minutes
To use the "Actuator as a slave with PUL function", to define the load to be controlled
and the "closed/open" state of the relay after resetting the actuator, use MYHOME_Suite
virtual configuration.
To use "Phase" (Single, 1, 2, 3), to select the "Load Type" and to select the "Load status
upon central unit enabling" use MYHOME_Suite virtual configuration.
1.2.2 Load control command
Virtual configuration (MYHOME_Suite) Physical configuration
Function Parameter / setting
Priority 1-63 P1,P2: 01-63
