355
HC4672N
L4672N
HS4672N
N4672N
HD4672N
NT4672N
LED signals according to the status of the actuator in automation mode:
Device status Two-colour LED Red LED
Load OFF GREEN OFF
Load ON ORANGE OFF
3) Automation and load control management mode:
In positions P1 and P2 priority from 01 to 63 must be indicated, in A and PL you need to
indicate the address of the device.
LED signals according to the status of the actuator in load control management
mode:
Device status Two-colour LED Red LED
Enabled ON ORANGE OFF
Enabled OFF GREEN OFF
Forced ORANGE flashing 1s/1s on GREEN OFF
Disabled GREEN ON steady
LED signals according to the status of the actuator in automation and load control
management mode:
Common LED notifications:
Device status Two-colour LED Red LED
Enabled + ON ORANGE OFF
Enabled + OFF GREEN OFF
Disabled GREEN ON steady
Forced + ON ORANGE flashing 1s/1s on GREEN OFF
Forced + OFF ORANGE flashing 1s/1s OFF
Device status Two-colour LED Red LED
Not configured ORANGE flashing
128 ms/128 ms on GREEN
OFF
Configuration error ORANGE flashing
irregularly on GREEN
OFF
2-module ush-mounted actuator 16A
MQ00363-d-EN 09/06/2014
