LEGRAND 3440 - Page 365

356
A
PL
M
G
P2
P1
L
L1
230V
230 Vac
C16
N
BUS – SCS
N L
HC4672N
L4672N
HS4672N
N4672N
HD4672N
NT4672N
Wiring diagrams
Actuator connection:
230 Vac
C16
N
LOAD
SCS – BUS
2-module ush-mounted actuator 16A
MQ00363-d-EN 09/06/2014
N L
NOTE: For loads with current draw greater than 16 A add a supporting relay between the actuator and the load.
