Load control panel
MQ00709-c-EN 07/06/2014
Virtual and physical configuration
Virtual configuration (MYHOME_Suite) Physical configuration
1)
Function Parameter / setting
Priority 0-63 P1 - ab address of tens for the loads assigned to buttons “a” and “b”, values from
0 to 6.
P2 - a address of units for the load assigned to button “a”, values from 0 to 9.
P2 - b address of units for the load assigned to button “b”, values from 0 to 9.
P1 - cd address of tens for the loads assigned to buttons “c” and “d”, values from
0 to 6.
P2 - c address of units for the load assigned to button “c”, values from 0 to 9.
P2 - d address of units for the load assigned to button “d”, values from 0 to 9.
M=0,1; mode, value 0, the device can be physically configured; value 1, the
device can be configured with the self-learning procedure.
To use "Phase" (Single, 1, 2, 3), use MYHOME_Suite virtual configuration.
NOTE 1:
For example: if I have to control the actuators with priority 5, 6, 12, 13, the load control
panel must be configured in the following way: P1-ab=0; P2-a=5; P2-b=6; P1-cd=1; P2-c=2; P2-
d=3. In this case button "a" is assigned to the actuator with priority 5, button "b" the actuator with
priority 6, button "c" the actuator with priority 12 and button "d" the actuator with priority 13.
In the load control system the highest priority that can be configured on the actuators is 63, so if at
P1-ab the connected configurator is 6 at P2-a or P2-b the connected configurator can be at most 3.
