TECHNICAL SHEETS
Conguration
The device must be congured as follows:
P - entrance panel number
The congurator in seat P of the speaker module assigns to it a recognition number
inside the system. The numbering of the entrance panels must always start from P=0.
The entrance panel congured with P=0 must be a common (or main) entrance panel.
N - call number
Assigns the correspondence between the entrance panel pushbuttons, and the audio
or video handsets.
In common entrance panels made using pushbutton modules, 1 must be inserted in N of
the speaker module. In secondary entrance panels, the number of the rst riser handset
must be inserted in N.
S - type of call signal
The conguration of S determines the call tone of the SPRINT handsets.
One can thus dierentiate the calls from dierent entrance panels.
Congurator 0 1 2 3
Type of bell 2-tone 2-tone 2-tone One-tone
1200Hz 1200Hz 1200Hz 1200Hz
600Hz 0 Hz 2400Hz
Table for SPRINT handset call signal
For the SWING, PIVOT, POLYX and AXOLUTE handsets, the S congurator associates the
Entrance panel to the bell programmed in the same apartment. It is possible to chose
between 16 dierent bells. In one-family systems S=9 congure the general call.
T - door lock relay timing
0= No
congurator
4 sec.
1
1 sec. 6 sec. 8 sec. 10 sec.
2
2 sec.
3
3 sec.
as
pushbutt.
4 5 6 7
congurator number
