“Push and Learn” self-learning type.
Configurazione
Select the operating mode
The device may operate in two different modes:
- Bistable (to operate the rolling shutter press and immediately release the UP or
DOWN keys).
- Monostable (to operate the rolling shutter press and hold down the UP or DOWN
keys).
The device is supplied configured in bistable mode. It will be possible to change the
operating mode at any time by pressing and holding down for more than 4 seconds
both the UP and DOWN keys of the rolling shutter control at the same time.
Adjustment of the blade position:
Press the UP and DOWN keys for more than 1 second.
Opening and closing the rolling shutter:
Press and release the UP and DOWN keys.
Use of the device in bistable mode
Shutter control
> 4 sec.
> 1 sec.
> 1 sec.
Shutter switch RF with preset function
