LEGRAND 3440 - Page 47

38
24/09/2013
50%
+ =
50%
+ =
50%
+ =
50%
+ =
50%
+ =
50%
+ =
50%
+ =
50%
+ =
0672 64
HA/HB4599
L/N4599N
078428
079128
663097
665111
Adjustment of the blade position:
Press the UP and DOWN pushbuttons for more than 1 second.
Use of the device in monostable mode
Opening and closing the rolling shutter:
Press and hold down the UP and DOWN Pushbuttons until the desired rolling shutter position.
Opening and closing the rolling shutter:
Press and release the UP and DOWN pushbuttons.
Use of the device in bistable mode
Shutter
actuator
Shutter
actuator
Shutter
actuator
Shutter
actuator
Shutter
actuator
Shutter
actuator
> 1 sec.
> 1 sec.
Shutter control RF
MQ00409-c-EN
