NOTA (*): If M=0, source 1 is switched on without rst switching OFF the sources (follow-me mode).
– Sound system control mode - FUN = 2
With this mode, for the associated amplier the user can control the switching ON or OFF,
the volume, the cycling through the sources, and their management (where allowed).
Information on the currently active source is also displayed.
In this mode the parameters that can be congured are the local address of the display (which
must coincide with the A/Pf address, and the M1 mode of the associated amplier), and the
name of the sources that can be controlled.
A Room 0 – 9, amplier room
PF Loudspeaker 1 – 9, Amplier loudspeaker
MOD Mode 0 – 8, Source switching ON (*)
FUN Function 2
Functions
A quick pressure of keys 5 and 7 will respectively switch ON and OFF the associated
amplier. If the associated amplier is on, an extended pressure of keys 5 and 7 may be
used to adjust the volume, the intensity of which will be displayed by means of an icon
5. A short pressure of keys 2 and 4, will respectively cycle through the sources installed in
the system, and launch a control for the currently activ
e source. If the associated amplier
is o and no source is on, the screen
will not show any information. Press key 4 for 3 seconds to congure the alarm clock (see
the user manual for details).
Legend
1. Indication of the amplier status or radio frequency
2. Cycling of sources (radio/aux)
3. Active source indication
4. Change radio station
5. Associated amplier OFF and volume decrease
6. Volume level indication
7. Associated amplier ON and volume increase
