49
3477
MQ00272-c-EN 07/06/2014
Basic contacts interface
2. Automation control
2.1 Addressing
Address type Virtual configuration (MYHOME_Suite) Physical configuration
Point-to-point Room 0-10 A=1-9
Lighting point 0-15 PL1, PL2=0-9
Room 0-10 A=AMB
Group 1-255 A=GR
General general A=GEN
missing in XLS
2.2 Mode
Virtual configuration (MYHOME_Suite) Physical configuration
Function Parameter / setting
Type of contact to terminals PL1 and PL2 Normally open (N/O) SPE=0
Normally closed (N/C) SPE=7
Bistable control
PL1=PL2 SPE=0 M=
Monostable control
PL1=PL2 SPE=0 M=M
3. Device locking/unlocking
3.1 Addressing
Address type Virtual configuration (MYHOME_Suite) Physical configuration
Point-to-point Room 0-10 A=1-9
Lighting point 0-15 PL1, PL2=0-9
Room 0-10 A=AMB
Group 1-255 A=GR
General General A=GEN
NOTE: With the virtual configuration, for the room, group and general controls, you can set a light
point address for the return of the load status
Installation and destination level:
The special control can also be used in systems where there are SCS/SCS interfaces (F422).
By installing the control on the BUS of an interface (installation level), you can control one
or more actuators located on the BUS of another interface (destination level).
Function Virtual configuration (MYHOME_Suite) Physical configuration
Destination level Local bus 1-15 I= 1-9
Riser bus riser I=CEN
Complete system entire system I=0
