1.2.2 ON/OFF Control and ADJUSTMENT (Point-to-Point only):
Virtual configuration (MYHOME_Suite) Physical configuration
Parameter / setting
ON/OFF and cyclic ADJUSTMENT
ON/OFF when pressing briefly and adjustment when holding down
SPE=0, M=O
ON with button at PL2, OFF with button at PL1 and DIMMER when held down SPE=0, M=O/I
ON with adjustment at 10% SPE=3, M=1
ON with adjustment at 20% SPE=3, M=2
ON with adjustment at 30% SPE=3, M=3
ON with adjustment at 40% SPE=3, M=4
ON with adjustment at 50% SPE=3, M=5
ON with adjustment at 60% SPE=3, M=6
ON with adjustment at 70% SPE=3, M=7
ON with adjustment at 80% SPE=3, M=8
ON with adjustment at 90% SPE=3, M=9
1.2.3 Blink command
When an actuator receives a blink command, it implements it by closing and opening
the relay for a time equal to T that can be configured as shown in the table.
Combine it with a command configured OFF to switch it off.
Virtual configuration (MYHOME_Suite) Physical configuration
Parameter / setting
Blink 0.5 s SPE=2, M=0
Blink 1 s SPE=2, M=1
Blink 1.5 s SPE=2, M=2
Blink 2 s SPE=2, M=3
Blink 2.5 s SPE=2, M=4
Blink 3 s SPE=2, M=5
Blink 3.5 s SPE=2, M=6
Blink 4 s SPE=2, M=7
Blink 4.5 s SPE=2, M=8
Blink 5 s SPE=2, M=9
For blinking with a period of from 5.5 to 8 seconds, use MYHOME_Suite virtual configuration
For the functions of "Cyclic with custom point-to-point adjustment", "Cyclic with
custom adjustment", "Cyclic dimmer without adjustment", "Custom dimmer ON without
adjustment", "Custom dimmer OFF without adjustment", "ON with custom adjustment",
"OFF with custom adjustment", use MYHOME_Suite virtual configuration.
