1.1 Addressing
Address type Virtual configuration (MYHOME_Suite) Physical configuration
Point-to-point Room 0-10 A=1-9
Lighting point 0-15 PL1, PL2=0-9
Room 0-10 A=AMB
Group 1-255 A=GR
General General A=GEN
NOTE: With the virtual configuration, for the room, group and general controls, you can set a light
point address for the return of the load status
missing in XLS
1.2 Mode
1.2.1 ON/OFF control:
Virtual configuration (MYHOME_Suite) Physical configuration
Function Parameter / setting
Type of contact to terminals PL1 and PL2 Normally open (N/O) SPE=0
Normally closed (N/C) SPE=7
Cyclic SPE=0, M=0
ON SPE=0, M=ON
OFF SPE=0, M=OFF
Cyclic (N/O contact only) SPE=1, M=7
Button SPE=0, M=PUL
ON with button at PL2, OFF with button at PL1 SPE=0, M=O/I
Timed ON 0.5sec SPE=0, M=8
2sec SPE=8, M=1
30sec SPE=0, M=7
1min SPE=0, M=1
2min SPE=0, M=2
3min SPE=0, M=3
4min SPE=0, M=4
5min SPE=0, M=5
10min SPE=8, M=2
15min SPE=0, M=6
For timed ON with period 0-255 hours, 0-59 minutes and 0-59 seconds use MYHOME_
Suite virtual configuration
1. Light switch
MQ00272-c-EN 07/06/2014
Basic contacts interface
Function selection
To configure the contact numbers use MYHOME_Suite virtual configuration
Installation and destination level:
The special control can also be used in systems where there are SCS/SCS interfaces (F422).
By installing the control on the BUS of an interface (installation level), you can control one
or more actuators located on the BUS of another interface (destination level).
Function Virtual configuration (MYHOME_Suite) Physical configuration
Destination level Local bus 1-15 I= 1-9
Riser bus riser I=CEN
Complete system entire system I=0
