If the device is installed in a My Home system it can be configured in two ways:
- PHYSICAL CONFIGURATION, inserting the configurators in position.
-
Configuration via MYHOME_Suite software package, downloadable from
www.homesystems-legrandgroup.com; this mode has the advantage of offering many
more options than the physical configuration.
For a list of the procedures and their meanings, please refer to the instructions in this
sheet and to the "Function Descriptions" help section in the MYHOME_Suite software
package.
When installed in a Lighting Management system, the actuator can be configured in the
following ways:
- PLUG&GO
- PROJECT&DOWNLOAD
Configuration
1.1 Addressing
Address type Virtual configuration (MYHOME_Suite) Physical configuration
Point-to-point Room 0-10 A=1-9
Lighting point 0-15 PL=1-9
Group Group 1 - Group 10 = 0-255 G1 = 0-9
To use the "Actuator as a slave with PUL function" and to adjust the "OFF delay", the
"Type of load" (Actuator, Lamp, Valve, Differential Reset, Fan, Irrigation, Controlled
Outlet, Lock) and the "Local button mode" (Cyclical, ON/OFF, ON-OFF, Pushbutton,
Timed ON) use MYHOME_Suite virtual configuration.
1. Light switch
NOTE 1): In the Master and Master PUL mode you can set an OFF delay of 0-255 seconds (via MY-
HOME_Suite) and of 1-4 minutes using the physical configuration. With the OFF control the Master
actuator deactivates; the Slave actuator deactivates after the time set with the configurators has
elapsed. The value of the configurator listed in the table defines the final time, after which the
actuator deactivates its own Slave.
This mode is only operative if PL1≠PL2.
1.2 Mode
Virtual configuration (MYHOME_Suite) Physical configuration
Function Parameter / setting
Master Actuator Master M=0
Actuator as Slave. Receives a control sent by a Master actuator
with the same address
Slave M=SLA
Pushbutton (ON monostable) ignores Room and General controls Master PUL M=PUL
OFF delay: Master actuator with OFF control delayed on the
corresponding Slave actuator.
1)
0 - 255 M=1 1 minute
M=2 2 minutes
M=3 3 minutes
M=4 4 minutes
