F411/2
2 relay actuator 6A
MQ00275-e-EN 07/06/2014
2. Automation control
2.1 Addressing
Address type Virtual configuration (MYHOME_Suite) Physical configuration
Point-to-point Room 0-10 A=1-9
Lighting point 0-15 PL1, PL2=1-9
Group Group 1 - Group 10: 0-255 G1:0-9
2.2 Mode
Virtual configuration (MYHOME_Suite) Physical configuration
Function Parameter / setting
Master Actuator Master M=0
Actuator as Slave. Receives a control sent by a Master actuator
with the same address
Slave M=SLA
Pushbutton (ON monostable) ignores Room and General controls Master PUL M=PUL
Timed stop. The actuator switches off after the set time has
elapsed.
This mode is only operative if PL1=PL2.
1-60 seconds,
2-10 minutes,
∞
M=0 1 minute
M=1 2 minutes
M=2 5 minutes
M=3 10 minutes
M=4 Until the motor's limit stop
M=5 20 seconds
M=6 10 seconds
M=7 5 seconds
M=8 15 seconds
M=9 30 seconds
T
o use the "Actuator as a slave with PUL function" and to adjust the "OFF delay", the
"Type of load" (Actuator, Rolling Shutter, Curtain, Gate, Rocker) and the "Local button
mode" (Cyclical, ON/OFF, ON-OFF, Pushbutton, Timed ON) use MYHOME_Suite virtual
configuration.
NOTE:
If PL1=PL2 the 2 relays are interlocked
