Dimmer for Electronic Ballast 1-10V
MQ00277-e-EN 07/06/2014
NOTE 2): In the physical configuration, the configurator in the L position establishes the minimum
output voltage between clamps 1 and 2 when the load is on, thus allowing the minimum
brightness level to be selected. 5 different voltage levels can be selected, so that the standard
0-10V is possible as well as the standard 1-10V.
NOTE 3): In the physical configuration, the configurator in the TYPE position determines the
type of load used on the basis of the following table. If ballasts for fluorescent lamps with typical
switching ON delay of 1.5s are used, the device will send the soft/start switching ON command
taking account of the delay. If power supply units for LED lamps must be controlled instead, the
device will send an immediate soft/start switching ON command.
1.2 Mode
Virtual configuration (MYHOME_Suite) Physical configuration
Function Parameter / setting
Master Actuator Master M=0
Actuator as Slave. Receives a control sent by a Master actuator
with the same address
Slave M=SLA
Pushbutton (ON monostable) ignores Room and General controls Master PUL M=PUL
OFF delay: Master actuator with OFF control delayed on the
corresponding Slave actuator.
1)
0 - 255 M=1 1 minute
M=2 2 minutes
M=3 3 minutes
M=4 4 minutes
Selection of the minimum brightness level
2)
1-100
L=0 1 Volt
L=1 1.5 Volt
L=2 2 Volt
L=3 0 Volt
L=4 0.5 Volt
Selection of the type of load used
3)
Fluorescent lamps TYPE=0 Fluorescent lamps
LED lamp TYPE=1 LED lamp
NOTE 1): In the Master and Master PUL mode you can set an OFF delay of 0-255 seconds (via
MYHOME_Suite) and of 1-4 minutes using the physical configuration. Only for point-point control.
With the OFF control the Master actuator deactivates; the Slave actuator deactivates after the
time set with the configurators has elapsed. The ON control activates the Master actuator and the
Slave actuator at the same time. The next OFF control deactivates the Master actuator and keeps
the Slave actuator active for the period of time set with configurator 1 - 4 connected to M of the
Master actuator as indicated in the table.
To use the “Actuator as a slave with PUL function”, for additional options of the “Type of
load” (Dali standard, DSI, Halogen lamp, Trailing edge LED / electronic transformers) and
for adjusting the voltage, use MYHOME_Suite virtual configuration.
When installed in a Lighting Management system, the device can be configured in the
following ways:
- Push & Learn: procedure for pairing different connected devices or changing the
assignments defined automatically in the Plug & Go procedure. For more details, please
refer to the specific document.
- Software Configuration: using the Virtual Configurator software; for more details, please
refer to the specific manual.
