F414
F415
F414/127
F415/127
Dimmer 1000VA
MQ00278-e-EN 07/06/2014
If the device is installed in a My Home system it can be configured in two ways:
- PHYSICAL CONFIGURATION, inserting the configurators in position.
-
Configuration via MYHOME_Suite software package, downloadable from
www.homesystems-legrandgroup.com; this mode has the advantage of offering many
more options than the physical configuration.
For a list of the procedures and their meanings, please refer to the instructions in this
sheet and to the "Function Descriptions" help section in the MYHOME_Suite software
package.
Configuration
1.1 Addressing
Address type Virtual configuration (MYHOME_Suite) Physical configuration
Point-to-point Room 0-10 A = 1-9
Lighting point 0-15 PL = 1-9
Group Group 1 - Group 10 = 0-255 G = 0-9
NOTE 1): In the Master and Master PUL mode you can set an OFF delay of 0-255 seconds (via
MYHOME_Suite) and of 1-4 minutes using the physical configuration. Only for point-point control.
With the OFF control the Master actuator deactivates; the Slave actuator deactivates after the time
set with the configurators has elapsed.
The ON control activates the Master actuator and the Slave actuator at the same time. The next
OFF control deactivates the Master actuator and keeps the Slave actuator active for the period of
time set with configurator 1 - 4 connected to M of the Master actuator as indicated in the table.
1.2 Mode
Virtual configuration (MYHOME_Suite) Physical configuration
Function Parameter / setting
Master Actuator Master M=0
Actuator as Slave. Receives a control sent by a Master actuator
with the same address
Slave M=SLA
Pushbutton (ON monostable) ignores Room and General controls Master PUL M=PUL
OFF delay: Master actuator with OFF control delayed on the
corresponding Slave actuator.
1)
0 - 255 M=1 1 minute
M=2 2 minutes
M=3 3 minutes
M=4 4 minutes
To use the "Actuator as a slave with PUL function" and adjust the "Minimum brightness
level at power-on" use MYHOME_Suite virtual configuration
