7.5.4 Print Go and Print Go Gate
Figure 75
The touch field <PrintGo> (106) toggles
between “intern” and “sensor” to select the
source of the print go signal.
With the “Sensor” setting the print go
signal will be generated through an
external sensor. With the “Internal”
setting the connected sensor is not
queried (the print go signal will be
generated by the printer).
With the touch field <PG-gate> (107) a further print start condition can be activated, at
the same time the current status “ON” or “OFF” is shown in the field in addition. With
the setting “ON” activated the print procedure is only carried out for as long as the
queried sensor is under voltage.
Example:
Endless print-out of pipes with interrupts between the end of the previos pipe
and the beginning of the next pipe.
[E4]
106
107
