Group 4 Technical data Page 29
Release 3.00 Leibinger-Jet 2 se
Potential free inputs: Optional 12 for special functions
Outputs: NPN 24 V, 500 mA, e. g. for device status and error
notifications
Data entry: Standard ASCII characters via V 24/RS 232
Data buffering in the event of voltage failure
Transmission speed 38400 Baud
4.4 Power parameters
Printing power
Character height: approx.
! min.: 0.8 mm
! max.: 12 mm,
depending on form of font, head distance, nozzle
diameter, ink and product surface
(e.g. 40 prints/sec with 10 characters)
Writing speed max. 2700 characters/s (at 96 kHz)
Character density
e.g. 26 characters/80 mm at 140 m/min product
speed (5x5 matrix)
(see calculation of the inscription speed in the group
Appendix)
4.5 Font forms
All type forms can be combined as desired in the writing
Printing of 1-4 lines or 24 dot matrix
Double spaced type, rapid
Micro type
Chimney type 5x7 matrix
Negative type
Capitals and non-capitals, umlauts, special characters
Matrix forms: 5x5, 7x5, 9x5, 9x7, 16x10, 11x8, 12x8,
14x10, 24x24,
Bern 16 (16x11-matrix),
Bern 24 (24x18-matrix)
Barm 16 (16x12-matrix)
Graphics
Graphics character record
Graphics 1 to 24 dot
Bold print
Contrast type
