Group 7 Data Entry Page 109
Release 3.00 Leibinger-Jet 2 se
7.6.5 Counter programming
To programm a counter you have to proceed as following:
(E.g.: A counter with 4 digits should be defined)
! Press the touch field < new text> in the menu level <E3>.
! The “font menu” <E9> is called up.
! After choosing the font the line menu <E15> either the keyboard field <E50> will be
displayed if necessary.
! By the touch field <Shift> scroll as long as the menu level <E60> appears.
! Press the touch field <Counter> (142). The Leibinger-Jet 2 changes to the counter
definition mode. To indicate that the counter definition mode is active, the display
background will be colored black.
! Return with the <Shift>-button (143) to the keyboard field <E50>.
! Input wildcard for the counter. The amount of the wildcards is determined by the
number of digits of the counter. The wildcards are already the so-called “start value”
of the counter (so e.g. 0005).
! Return with the <Shift>-button (143) to the menu level <E60> again and confirm the
input by pressing the touch field <counter> (144) again.
! Escape the menu with the <Shift>-button (143) and you can finish the process in the
next possible menu level by pressing the touch field <ESCAPE>.
! With the touch field <take over> (145) in the menu level <E1> the counter will be
taken over into the production.
! A safety inquiry with which counter you should go on will be faded-in.
Observation:
The touch field <take over > will be only displayed during open nozzle!
The parameters of the counter can be selected in the menu level <E6>.
The value of the entered wildcards determines also the “start value” of the counter. For
the first start of the production it will be only once from the “start value” (wildcard) to the
“initial value”. Afterwards it will be only counted recurrently from the “initial value” to the
“end value”.
