Group 6 Operation – procedures and elements Page 53
Release 3.00 Leibinger-Jet 2 se
6.3.4 Potentiometer – Display illumination
Allows for the adjustment of the display brightness. By means of turning the adjusting
screw the brightness can be adapted to the ambience condition in order to ensure
optimum readability. The potentiometer is located in the electronics cabinet on the
controller board (also see figure in chapter 6.5.2).
Figure 22
1– Potentiometer
- Display illumination
1
