Leibinger Jet 2 - Page 162

Group 12 Appendix Page 162
Release 3.00 Leibinger-Jet 2 se
Matrix Draft
Number
of lines
CPI
Stroke
distance
V max
in m/min
V max
in m/s
Factor
T=a/V
Matrix Draft
Number
of lines
CPI
Stroke
distance
V max
in m/min
V max
in m/s
Factor
T=a/V
5x5 0 1 10 0,4305 178,869 2,981 0,144 5x5 0 1 10 0,4305 166,798 2,780 0,155
5x5 0 2 / 16 Dot 10 0,4305 49,381 0,823 0,523 5x5 0 2 / 16 Dot 10 0,4305 43,894 0,732 0,588
5x5 0 3 / 16 Dot 10 0,4305 46,089 0,768
0,560
5x5 0 3 / 16 Dot 10 0,4305 40,602 0,677
0,636
5x5 0 2 / 24 Dot 10 0,4305 29,629 0,494
0,872
5x5 0 2 / 24 Dot 10 0,4305 30,726 0,512
0,841
5x5 0 3 / 24 Dot 10 0,4305 29,629 0,494 0,872 5x5 0 3 / 24 Dot 10 0,4305 30,726 0,512 0,841
5x5 0 4 / 24 Dot 10 0,4305 29,629 0,494 0,872 5x5 0 4 / 24 Dot 10 0,4305 29,629 0,494 0,872
5x5 1 1 10 0,4305 249,100 4,152
0,104
5x5 1 1 10 0,4305 166,798 2,780
0,155
5x5 1 2 / 16 Dot 10 0,4305 71,328 1,189
0,362
5x5 1 2 / 16 Dot 10 0,4305 44,992 0,750
0,574
5x5 1 3 / 16 Dot 10 0,4305 65,841 1,097 0,392 5x5 1 3 / 16 Dot 10 0,4305 41,700 0,695 0,619
5x5 2 1 10 0,4305 365,420 6,090 0,071 5x5 2 1 10 0,4305 271,047 4,517 0,095
5x5 2 2 schnell 10 0,4305 151,870 2,531
0,170
5x5 2 2 schnell 10 0,4305 101,240 1,687
0,255
5x5 3 1 10 0,4305 249,100 4,152
0,104
5x5 3 1 10 0,4305 166,798 2,780
0,155
5x5 3 2 / 16 Dot 10 0,4305 71,328 1,189 0,362 5x5 3 2 / 16 Dot 10 0,4305 44,992 0,750 0,574
5x5 3 3 / 16 Dot 10 0,4305 65,841 1,097 0,392 5x5 3 3 / 16 Dot 10 0,4305 41,700 0,695 0,619
5x5 3 2 / 24 Dot 10 0,4305 47,186 0,786
0,547
5x5 3 2 / 24 Dot 10 0,4305 41,700 0,695
0,619
5x5 3 3 / 24 Dot 10 0,4305 47,186 0,786
0,547
5x5 3 3 / 24 Dot 10 0,4305 30,726 0,512
0,841
5x5 3 4 / 24 Dot 10 0,4305 46,089 0,768 0,560 5x5 3 4 / 24 Dot 10 0,4305 29,629 0,494 0,872
5x5 4 1 10 0,4305 177,772 2,963 0,145 5x5 4 1 10 0,4305 166,798 2,780 0,155
5x5 4 2 / 16 Dot 10 0,4305 49,381 0,823
0,523
5x5 4 2 / 16 Dot 10 0,4305 44,992 0,750
0,574
5x5 4 3 / 16 Dot 10 0,4305 46,089 0,768
0,560
5x5 4 3 / 16 Dot 10 0,4305 41,700 0,695
0,619
5x5 4 2 / 24 Dot 10 0,4305 28,531 0,476 0,905 5x5 4 2 / 24 Dot 10 0,4305 30,726 0,512 0,841
5x5 4 3 / 24 Dot 10 0,4305 29,629 0,494 0,872 5x5 4 3 / 24 Dot 10 0,4305 30,726 0,512 0,841
5x5 4 4 / 24 Dot 10 0,4305 29,629 0,494
0,872
5x5 4 4 / 24 Dot 10 0,4305 29,629 0,494
0,872
7x5 0 1 10 0,4305 127,294 2,122 0,203 7x5 0 1 10 0,4305 118,515 1,975 0,218
7x5 0 2 / 16 Dot 10 0,4305 49,381 0,823 0,523 7x5 0 2 / 16 Dot 10 0,4305 40,602 0,677 0,636
7x5 0 2 / 24 Dot 10 0,4305 29,629 0,494
0,872
7x5 0 2 / 24 Dot 10 0,4305 29,629 0,494
0,872
7x5 0 3 / 24 Dot 10 0,4305 29,629 0,494
0,872
7x5 0 3 / 24 Dot 10 0,4305 29,629 0,494
0,872
7x5 1 1 10 0,4305 178,869 2,981 0,144 7x5 1 1 10 0,4305 118,515 1,975 0,218
7x5 1 2 / 16 Dot 10 0,4305 69,134 1,152 0,374 7x5 1 2 / 16 Dot 10 0,4305 40,602 0,677 0,636
7x5 2 1 10 0,4305 310,552 5,176
0,083
7x5 2 1 10 0,4305 203,011 3,384
0,127
7x5 2 2 schnell 10 0,4305 136,500 2,275
0,189
7x5 2 2 schnell 10 0,4305 91,000 1,520
0,284
7x5 3 1 10 0,4305 177,772 2,963 0,145 7x5 3 1 10 0,4305 118,515 1,975 0,218
7x5 3 2 / 16 Dot 10 0,4305 69,134 1,152 0,374 7x5 3 2 / 16 Dot 10 0,4305 40,602 0,677 0,636
7x5 3 2 / 24 Dot 10 0,4305 47,186 0,786
0,547
7x5 3 2 / 24 Dot 10 0,4305 29,629 0,494
0,872
7x5 3 3 / 24 Dot 10 0,4305 46,089 0,768
0,560
7x5 3 3 / 24 Dot 10 0,4305 29,629 0,494
0,872
7x5 4 1 10 0,4305 127,294 2,122 0,203 7x5 4 1 10 0,4305 118,515 1,975 0,218
7x5 4 2 / 16 Dot 10 0,4305 49,381 0,823 0,523 7x5 4 2 / 16 Dot 10 0,4305 40,602 0,677 0,636
7x5 4 2 / 24 Dot 10 0,4305 29,629 0,494
0,872
7x5 4 2 / 24 Dot 10 0,4305 29,629 0,494
0,872
7x5 4 3 / 24 Dot 10 0,4305 29,629 0,494 0,872 7x5 4 3 / 24 Dot 10 0,4305 29,629 0,494 0,872
9x5 0 1 10 0,4305 94,373 1,573 0,274 9x5 0 1 10 0,4305 91,081 1,518 0,284
9x5 0 2 / 24 Dot 10 0,4305 29,629 0,494
0,872
9x5 0 2 / 24 Dot 10 0,4305 30,726 0,512
0,841
9x5 1 1 10 0,4305 136,072 2,268 0,190 9x5 1 1 10 0,4305 92,178 1,536 0,280
9x5 2 1 10 0,4305 249,100 4,152 0,104 9x5 2 1 10 0,4305 162,409 2,707 0,159
9x5 3 1 10 0,4305 136,072 2,268 0,190 9x5 3 1 10 0,4305 91,081 1,518 0,284
9x5 3 2 / 24 Dot 10 0,4305 48,284 0,805
0,535
9x5 3 2 / 24 Dot 10 0,4305 30,726 0,512
0,841
9x5 4 1 10 0,4305 94,373 1,573 0,274 9x5 4 1 10 0,4305 91,081 1,518 0,284
9x5 4 2 / 24 Dot 10 0,4305 29,629 0,494 0,872 9x5 4 2 / 24 Dot 10 0,4305 30,726 0,512 0,841
9x7 0 1 8 0,4032 88,886 1,481
0,272
9x7 0 1 8 0,4032 85,594 1,427
0,283
9x7 0 2 / 24 Dot 8 0,4032 27,434 0,457 0,882 9x7 0 2 / 24 Dot 8 0,4032 28,531 0,476 0,848
9x7 1 1 8 0,4032 130,586 2,176 0,185 9x7 1 1 8 0,4032 85,594 1,427 0,283
9x7 2 1 8 0,4032 229,348 3,822
0,105
9x7 2 1 8 0,4032 151,435 2,524
0,160
9x7 3 1 8 0,4032 130,586 2,176
0,185
9x7 3 1 8 0,4032 85,594 1,427
0,283
9x7 3 2 / 24 Dot 8 0,4032 43,894 0,732 0,551 9x7 3 2 / 24 Dot 8 0,4032 28,531 0,476 0,848
9x7 4 1 8 0,4032 88,886 1,481 0,272 9x7 4 1 8 0,4032 85,594 1,427 0,283
9x7 4 2 / 24 Dot
8
0,403
2
27,434 0,457 0,882 9x7 4 2 / 24 Dot
8
0,403
2
28,531 0,476 0,848
96 KHz 64 KHz
