7 Programs
7.1 General
7.1.1 Common Fields
The following table describes common elds that are found within the pro-
grams.
Field Description
PtID Point ID of the point.
Backsight Pt /
PtBS
Point ID of backsight point.
Foresight Pt Point ID of foresight point.
Start height /
Start H
Height of starting point.
Height BS Height of backsight point.
Height FS Height of foresight point.
Total dH Sum of the height differences determined between the
rst backsight and the current foresight/backsight obser-
vation.
Instr.Horizon Instrument horizon: Height of line of sight.
Staff Height reading on levelling staff.
Distance Distance between instrument and levelling staff
Total Dist Sum of the distances measured between the rst back-
sight and the current foresight/backsight observation.
Dist.Balance Difference between the sum of all foresight distances and
the sum of all backsight distances. For high precision line
levelling, the distance balance at the end of the line should
be close to zero.
Stat.ID ID of current instrument station.
Rem. /
Remark /
Code
Remark (Rem.) or Code name depending on the selected
method.
•
Remark: This text is an additional information stored
to the corresponding measurement.
•
Code: Within the Code tab, highlight a code from the
code list. The highlighted code is added to the meas-
urement that is stored next. For details on adding or
editing a code refer to 9 Coding.
East Easting coordinate of the point.
North Northing coordinate of the point.
Height Height coordinate of the point.
7.1.2 Point Search
Pointsearch is a function to nd measured points or xpoints in the memory
storage.
Description of elds
Description
48 Programs
