4-6 Description and Operation
D-H001.0609EN
In this manual the arrow up and arrow down are not shown, the menu is extended and all the options are
shown.
Example menu
Option 1>
Option 2
Option 3
Option 4
Option 5
In this manual the following annotation is used when the operator must select Sub 2:
Example menu > Option 1 > Sub 2
X-link
The X-link controls and monitors the milking robot and communicates with the T4C management software. The
X-link also stores some historical and actual cow data. This enables the milking robot to continue operation if a
communication error occurs between T4C and the X-link.
The touchscreen, navigation button and the two push buttons enable the user to give commands and change
values in the milking robot. The touchscreen also shows reports and alarms.
The touchscreen interface has quick-launch buttons for easy operation of some functions. These functions are
also in other places in the X-link menu. There are tabs for:
Process
Settings
Test
Indications
System
T4C
Service
Sampling (this tab only appears when sampling has been selected).
During normal operation of the milking robot the process tab of the X-link changes each time the status of the
milking robot changes. Pop-up windows can also appear during operation of the milking robot. The pop-up
windows show alarms or ask the operator to make a decision. These pop-up windows appear when any tab is
selected.
