Operation
75

Turn the plough into the right-hand work-
ing position.
 Remove the pin (1).
 Detach the hydraulic ram (2) from the
wheel stalk (3).

Swivel the hydraulic ram (2) to the stop
(4).

Raise the plough using the tractor’s hy-
draulic system.
 Release the pin (5).
 Pull the pin (5) up.
 Pivot the wheel through 90°.
 Lock the wheel using the pin (5).
 Secure the pin (5) with the linch pin.
1
3
2
4
4
5
