Operation
76
Swivel the locking pin (6) on the front of
the turnover device through 180°.
Important: Always carry out the steps in the order specified.
Raise the plough.
Set the plough to the smallest working width (V version).
Turn the plough slowly until you hear the locking pin (8) engage.
Check that the locking pin (8) is engaged correctly.
Lower the plough using the tractor’s hydraulic system.
Disconnect the top link from the headstock.
Raise the front of the plough = transport position.
6
