11 Appendix
11.1 Table of attributes
310
Lenze · i700 servo inverter · reference manual · DMS 3.0 EN · 06/2016 · TD06
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
0x10F3 Diagnostics: History buffer
1: Max. number of messages UNSIGNED_8 -
2: Latest message UNSIGNED_8 -
3: Latest acknowledged message UNSIGNED_8 -
4: Latest active message UNSIGNED_8 - Tx
5: Control bits UNSIGNED_16 -
0x10F8
ECAT DC: Current time UNSIGNED_64 - Tx
Manufacturer specific area
0x2000
Device: Data
1: Device: Product designation STRING(50) -
2: Device: Serial number STRING(50) -
3: Device: Manufacturing date STRING(50) -
0x2001 Device: Name STRING(128) - P
0x2020
EoE information
1: Virtual MAC address STRING(32) -
2: IP address STRING(32) -
3: Subnet mask STRING(32) -
4: Standard gateway STRING(32) -
5: DNS server STRING(32) -
6: DNS name STRING(50) -
7: Received packages UNSIGNED_32 -
8: Sent packages UNSIGNED_32 -
0x2021
Device: Optical recognition
1: Start optical recognition UNSIGNED_8 -
2: Optical recognition: Blinking time UNSIGNED_16 -
0x2022
Device command UNSIGNED_32 -
0x2030
Parameter set: Validity check (CRC) UNSIGNED_32 -
0x2100 Brand protection
1: Brand protection: Set pin INTEGER_32 -
2: Brand protection: Enter pin INTEGER_32 -
3: Brand protection: Encryption UNSIGNED_8 -
0x2500
Touch probe (TP): Debounce time UNSIGNED_16 - P
0x2540
Device: Voltage values
1: Mains: Rated voltage UNSIGNED_8 - P
2: Undervoltage (LU): Warning threshold UNSIGNED_16 - P
3: Undervoltage (LU): Error threshold UNSIGNED_16 - P
4: Undervoltage (LU): Threshold 'Reset error' UNSIGNED_16 - P
5: Overvoltage (OU): Warning threshold UNSIGNED_16 - P
6: Overvoltage (OU): Error threshold UNSIGNED_16 - P
7: Overvoltage (OU): Threshold 'Reset error' UNSIGNED_16 - P
8: Critical DC-bus voltage UNSIGNED_8 - Tx
0x2580 ECAT DC: Real-time information
1: ECAT DC: Status real-time information UNSIGNED_8 -
2: ECAT DC: Time stamp first real-time
information
UNSIGNED_64 -
3: ECAT DC: Time stamp last real-time
information
UNSIGNED_64 -
4: ECAT DC: Current time UNSIGNED_64 -
Axis A - holding brake control
Index Name Data type Factor Attributes
Greyed out = read only
