Action Yes No
Step 3
Reseat the cables and connector between the LSU and controller
board.
Does the problem remain?
Go to step 4. The problem is
solved.
Step 4
Check the cables for damages, and replace if necessary.
Does the problem remain?
Go to step 5. The problem is
solved.
Step 5
Check the LSU for proper installation.
a POR into the Diagnostics menu, and then perform a feed test:
Diagnostics Menu > Input Tray Test > Feed Test > select a tray
b Check the display to determine whether the test is successful.
c If the test fails, then perform the service check to resolve the
error code shown.
Does the problem remain?
Go to step 6. The problem is
solved.
Step 6
Check the LSU for damages, and replace if necessary.
Installation note: Mechanical and electronic LSU adjustments
are required to complete the installation of the LSU. See
“Printhead assembly adjustments” on page 225.
Does the problem remain?
Go to step 7. The problem is
solved.
Step 7
Check the LSU and controller board connector for damaged or
bent pins. Replace the part with damaged pins.
Does the problem remain?
Go to step 8. The problem is
solved.
Step 8
Replace the controller board.
Does the problem remain?
Contact the next
level of support.
The problem is
solved.
4514-6xx
Diagnostics and troubleshooting
137
