Service menus
Understanding the printer control panel
Using the printer control panel
MS510dn and MS610dn
1
2
3
4
5
6
7
8
9
10
11
12
13
# Use the To
1 Display View the printer status and messages.
Set up and operate the printer.
2 Left arrow button Scroll to the left.
3 Select button Select menu options.
Save settings.
4 Up arrow button Scroll up.
5 Right arrow button Scroll to the right.
6 Keypad Enter numbers, letters, or symbols.
7 Sleep button Enable Sleep mode or Hibernate mode.
The following actions wake the printer from Sleep mode:
• Pressing any hard button
• Opening a tray or the front door
• Sending a print job from the computer
• Performing a power‑on reset using the main power switch
• Attaching a device in the USB port
8 USB port Connect a flash drive to the printer.
Notes:
• Only the front USB port supports flash drives.
• This feature is available only in select printer models.
9 Stop or cancel button Stop all printer activities.
4514-6xx
Service menus
173
