Sensor Test
This test
verifies
that the output bin sensors are working correctly.
To run this test:
1 From the Diagnostics menu, navigate to:
Output Bin Tests > Sensor Test > Standard Bin
Testing... appears while the printer is verifying the state of the sensor.
The control panel displays the current state of the sensor.
2 Manually actuate the sensor to make it toggle between empty and full. If the sensor does not toggle,
then the sensor is malfunctioning.
3 Press X to exit the test.
BASE SENSOR TEST
Use the Base Sensor Test to determine that the sensors located inside the printer are operating correctly.
The following sensors can be checked using this test:
• Narrow Media
• Input
• Exit
• Front Door
CAUTION—SHOCK HAZARD: Do not use your hand to toggle these switches. Use a nonconducting
item.
To r un th e Ba s e S en so r Te s t.
1 From the Diagnostics menu, navigate to BASE SENSOR TEST.
2 Choose a sensor.
3 Manually actuate the sensor to verify that it toggles. If the sensor does not toggle, then it is malfunctioning.
Sensor Values
Input
Output
Front Door
Open
Closed
Narrow Media Narrow
Wide
4 Press X to exit the test.
4514-6xx
Service menus
183
