Lexmark M3150

Assembly 7: Power cords
Asm-index P/N Units/mach Units/FRU Description Removal procedure
NS 40X0269 1 1 Power cord, 2.5 m (straight)—USA, Canada N/A
NS 40X0289 1 1 Power cord, 1.8 m (straight)—USA N/A
NS 40X3141 1 1 Power cord, 2.5 m (straight)—Europe and
others
N/A
NS 40X0288 1 1 Power cord, 2.5 m (straight)—Argentina N/A
NS 40X0271 1 1 Power cord, 2.5 m (straight)—United
Kingdom
N/A
NS 40X0275 1 1 Power cord, 2.5 m (straight)—Israel N/A
NS 40X1772 1 1 Power cord, 2.5 m (straight)—Switzerland N/A
NS 40X1773 1 1 Power cord, 2.5 m (straight)—South Africa N/A
NS 40X0273 1 1 Power cord, 2.5 m (straight)—Traditional
Italy
N/A
NS 40X1774 1 1 Power cord, 2.5 m (straight)—Denmark N/A
NS 40X4596 1 1 Power cord, 2.5 m (straight)—Brazil N/A
NS 40X0303 1 1 Power cord, 2.5 m (straight)—China N/A
NS 40X0270 1 1 Power cord, 2.5 m (straight)—Japan N/A
NS 40X1792 1 1 Power cord, 2.5 m (straight)—Korea N/A
NS 40X1791 1 1 Power cord, 2.5 m (straight)—Taiwan N/A
NS 40X0301 1 1 Power cord, 2.5 m (straight)—Australia N/A
4514-6xx
Parts catalog
355
