Lexmark M3150

7 Remove the two screws (A) securing the reverse solenoid.
A
Cartridge gearbox removal
1 Remove the left cover. See “Left cover removal” on page 228.
2 Remove the four screws (A) securing the cartridge gearbox.
A
3 Disconnect the cable from the cartridge gearbox.
4514-6xx
Parts removal
238
