5 Remove the two screws (B) securing the fan to the fan mount.
B
Cooling fan removal (MS610de)
1
Remove the right cover. See “Right cover removal” on page 241.
2 Disconnect the cable JFAN1 from the controller board.
4514-6xx
Parts removal
244
