UICC removal (MS610de)
1 Remove the right cover. See “Right cover removal” on page 241.
2 Remove the nameplate. See “Nameplate removals” on page 263.
3 Remove the bezel. See “Bezel removals” on page 261.
4 Remove the control panel assembly. See “Control panel assembly removals” on page 265.
5 Disconnect the cable from the connector (A).
6 Remove the five screws (B).
A
B
4514-6xx
Parts removal
273
