Lexmark M3150

Assembly 2: Electronics 1
Asm-index P/N Units/mach Units/FRU Description Removal procedure
NS 41X0363 1 1 Polygon laser scanning unit
(LSU) frame*
‑‑
141X0362 1 1Polygon LSU*
“Laser scanning unit (LSU)
removal” on page 316
1 40X8080 1 1 Galvo LSU*
(MS510dn, MS517dn and
M1145)
“Laser scanning unit (LSU)
removal” on page 316
140X8079 1 1Galvo LSU*
(MS610dn, MS617dn,
MS610de, M3150dn, and
M3150)
“Laser scanning unit (LSU)
removal” on page 316
240X8343 1 1Fuser, 100 V
“Fuser removal” on page 314
2 40X8023 1 1 Fuser, 110 V
“Fuser removal” on page 314
240X8024 1 1Fuser, 220 V
“Fuser removal” on page 314
3 40X8050 1 1 Narrow media/bin full sensor
“Narrow media/bin full sensor
removal” on page 308
4 40X8276 1 1 Cooling fan
(MS510dn, MS517dn,
MS610dn, MS617dn, M1145,
and M3150dn)
“Cooling fan removals” on
page 243
4 40X9181 1 1 Cooling fan
(MS610de and M3150)
“Cooling fan removals” on
page 243
5 41X0366 1 1 Controller board*
(applicable only to models
MS510dn and MS517dn with
polygon LSU)
“Controller board removals” on
page 247
5 41X0367 1 1 Controller board*
(applicable only to models
MS610dn and MS617dn with
polygon LSU)
“Controller board removals” on
page 247
5 40X8029 1 1 Controller board*
(applicable only to models
MS510dn, MS517dn and
M1145 with galvo LSU)
“Controller board removals” on
page 247
5 40X8030 1 1 Controller board*
(applicable only to models
MS610dn, MS617dn and
M3150dn with galvo LSU)
“Controller board removals” on
page 247
4514-6xx
Parts catalog
340
