Lexmark M3150

Assembly 3: Electronics 2
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X8048 1 1 Front door sensor
“Front door sensor removal” on
page 284
2 40X8266 1 1 Cartridge smart chip
contact
“Toner cartridge smart chip contact
removal” on page 251
3 40X8046 1 1 Toner density sensor
“Toner density sensor removal” on
page 295
NS 41X1025 1 1 Toner density wiper kit
• RheoGel 739
(41X0986)
• toner density sensor
(40X8406)
‑‑
4 40X7797 1 1 Power supply, 100 V/110 V
“Power supply removal” on
page 289
4 40X7798 1 1 Power supply, 220 V
“Power supply removal” on
page 289
540X8044 1 1Index sensor
“Index sensor removal” on
page 295
6 40X8043 1 1 Duplex sensor and input
sensor
“Duplex sensor and input sensor
removal” on page 292
7 40X8800 1 1 Media present sensor flag
“Media present sensor flag
removal” on page 299
8 40X7592 1 1 Media present sensor
“Media present sensor removal” on
page 297
9 40X8045 1 1 Trailing edge sensor
“Trailing edge sensor removal” on
page 299
4514-6xx
Parts catalog
344
