Lexmark M3150

Assembly 4: Frame
Asm-index P/N Units/mach Units/FRU Description Removal procedure
140X8393 1 1Transfer roll
“Transfer roll removal” on
page 257
2 40X8298 1 1 Redrive assembly
(MS510dn, MS517dn and M1145)
Note: Before replacing this part,
check the important information
and installation instructions. See
the installation note in the
removal procedure.
“Redrive assembly removal”
on page 310
2 40X8437 1 1 Redrive assembly
(MS610dn, MS617dn and
M3150dn)
Note: Before replacing this part,
check the important information
and installation instructions. See
the installation note in the
removal procedure.
“Redrive assembly removal”
on page 310
2 40X8438 1 1 Redrive assembly
(MS610de, and M3150)
Note: Before replacing this part,
check the important information
and installation instructions. See
the installation note in the
removal procedure.
“Redrive assembly removal”
on page 310
3 40X8850 1 1 Redrive shaft
“Redrive shaft removal” on
page 313
4 40X8299 1 1 Front mounts
“Left front mount removal”
on page 253
“Right front mount removal”
on page 255
5 40X8084 1 1 Pick/Lift motor gearbox
“Pick/Lift motor gearbox
removal” on page 305
6 40X8275 1 1 Duplex assembly
“Duplex removal” on
page 291
7 41X0958 2 2 Pick tires N/A
8 41X0959 1 1 ACM assembly (standard tray
only)
“ACM assembly removal” on
page 303
4514-6xx
Parts catalog
347
