Lexmark MS823 Service Manual

Error code Description Action
88.00 The remaining life of the toner cartridge is nearly
low.
Replace the toner cartridge.
88.09 The remaining life of the toner cartridge is nearly
low.
88.10 The remaining life of the toner cartridge is low.
88.19 The remaining life of the toner cartridge is low.
88.20 The remaining life of the toner cartridge is very
low.
88.29 The remaining life of the toner cartridge is very
low.
88.30 The toner cartridge life has ended.
88.40 The toner cartridge life has ended. The printer
forces a hard stop on the toner cartridge.
88.48 The toner cartridge life has ended. The printer
forces a hard stop on the toner cartridge.
Printer hardware errors
111 errors
111 error messages
Error code Description Action
111.20 Printhead error (mirror motor lock) was detected
before the motor was turned on.
See
“Printhead error service check” on
page 303.
111.21 No printhead power (+5V) when the laser servo
started.
111.30 The printhead failed during power on tests. See
“Printhead error service check” on
page 303.
111.31 Printhead error (no first HSYNC) was detected.
111.32 Printhead error (lost HSYNC) was detected.
111.33 Printhead error (lost HSYNC) was detected during
servo.
111.34 Printhead error (mirror motor lost lock) was
detected.
111.35 Printhead error (mirror motor never got first lock)
was detected.
111.36 Printhead error (mirror motor lock never
stabilized) was detected.
4064
Diagnostics and troubleshooting
302

Lexmark MS823 Specifications

General

Print Technology	Monochrome Laser
Print Speed	Up to 65 ppm
Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 300, 000 pages
Recommended Monthly Page Volume	5, 000 - 75, 000 pages
Processor Speed	1 GHz
Standard Memory	512 MB
Connectivity	USB, Ethernet
Standard Input Capacity	650 pages
Maximum Paper Input	4, 400 sheets
Media Types Supported	Plain paper, Card stock, Envelopes, Labels, Transparencies
Operating System Compatibility	Windows, Linux
Duplex Printing	Automatic
