Lexmark MS823 Service Manual

3 Remove the screw (A), and then disconnect the sensor cable (B).
4 Remove the sensor.
Bin cover removal
1 Remove the control panel (4.3-inch display). See “Control panel (4.3-inch display) removal” on page
442.
2 Remove the top cover. See “Top cover removal” on page 455.
3 Remove the left cover. See “Left cover removal” on page 409.
4 Remove the right cover. See “Right cover removal” on page 420.
5 Remove the rear door. See “Rear door removal” on page 449.
6 Remove the redrive. See “Upper redrive removal” on page 453.
7 Remove the bin full sensor cover. See “Bin full sensor cover removal” on page 460.
8 Remove the sensor (standard bin full). See “Sensor (standard bin full) removal” on page 460.
4064
Parts removal
461

Lexmark MS823 Specifications

General

Print Technology	Monochrome Laser
Print Speed	Up to 65 ppm
Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 300, 000 pages
Recommended Monthly Page Volume	5, 000 - 75, 000 pages
Processor Speed	1 GHz
Standard Memory	512 MB
Connectivity	USB, Ethernet
Standard Input Capacity	650 pages
Maximum Paper Input	4, 400 sheets
Media Types Supported	Plain paper, Card stock, Envelopes, Labels, Transparencies
Operating System Compatibility	Windows, Linux
Duplex Printing	Automatic
