Lexmark MS823 Service Manual

4 Unhook the spring (B) from the frame, and then remove the tensioner from the frame.
Output expander bin removal
1 Remove the output expander left cover. See “Output expander left cover removal” on page 522.
2 Remove the output expander right cover. See “Output expander right cover removal” on page 520.
3 Disconnect the cable J10 from the controller board.
4 Remove the seven screws (A), to release the left inner frame.
4064
Parts removal
541

Lexmark MS823 Specifications

General

Print Technology	Monochrome Laser
Print Speed	Up to 65 ppm
Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 300, 000 pages
Recommended Monthly Page Volume	5, 000 - 75, 000 pages
Processor Speed	1 GHz
Standard Memory	512 MB
Connectivity	USB, Ethernet
Standard Input Capacity	650 pages
Maximum Paper Input	4, 400 sheets
Media Types Supported	Plain paper, Card stock, Envelopes, Labels, Transparencies
Operating System Compatibility	Windows, Linux
Duplex Printing	Automatic
