Lexmark MS823 - Motor (MPF) Removal

4 Remove the two screws (C), and then remove the fan.
Motor (MPF) removal
1 Remove the top cover. See “Top cover removal” on page 455.
2 Remove the left cover. See “Left cover removal” on page 409.
4064
Parts removal
413
