Assembly 2: Fuser
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 41X2147 1 1 HR fuser, 115V Contact Detack LRP
TYPE 11
Note: This fuser is not applicable to
MX721, MX722, MS82x, MX82x,
B2865, MB2770, M52xx, XM5365,
XM5370, and XM73xx printer models.
“Fuser removal” on
page 452
1 41X2148 1 1 HR fuser, 220V Contact Detack LRP
TYPE 13
Note: This fuser is not applicable to
MX721, MX722, MS82x, MX82x,
B2865, MB2770, M52xx, XM5365,
XM5370, and XM73xx printer models.
“Fuser removal” on
page 452
1 41X2149 1 1 HR fuser, 115V Contact Detack NLRP
TYPE 17
Note: This fuser is not applicable to
MX721, MX722, MS82x, MX82x,
B2865, MB2770, M52xx, XM5365,
XM5370, and XM73xx printer models.
“Fuser removal” on
page 452
1 41X2150 1 1 HR fuser, 220V Contact Detack NLRP
TYPE 19
Note: This fuser is not applicable to
MX721, MX722, MS82x, MX82x,
B2865, MB2770, M52xx, XM5365,
XM5370, and XM73xx printer models.
“Fuser removal” on
page 452
2 41X1115 1 1 Belt SY fuser, 115V LTR LRP TYPE 00
Note: This fuser is not applicable to
MS725 and MX725 printer models.
“Fuser removal” on
page 452
2 41X1116 1 1 Belt SY fuser, 230V A4 LRP TYPE 01
Note: This fuser is not applicable to
MS725 and MX725 printer models.
“Fuser removal” on
page 452
2 41X1117 1 1 Belt SY fuser, 100V A4 LRP TYPE 02
Note: This fuser is not applicable to
MS725 and MX725 printer models.
“Fuser removal” on
page 452
2 41X2141 1 1 Belt SY fuser, 115V A4 LRP TYPE 03
Note: This fuser is not applicable to
MS725 and MX725 printer models.
“Fuser removal” on
page 452
2 41X2142 1 1 Belt SY fuser, 230V LTR LRP TYPE 04
Note: This fuser is not applicable to
MS725 and MX725 printer models.
“Fuser removal” on
page 452
