Lexmark MS823 Service Manual

Assembly 16: 250- and 550-sheet tray options 2
Asm-index P/N Units/mach Units/FRU Description Removal procedure
141X1655 1 1Interface cable
“250‑ and 550-sheet tray interface
cable removal” on page 510
241X1093 1 1Sensor (pick)
“Sensor (250‑ and 550-sheet tray pick)
removal” on page 507
341X1094 1 1Sensor (pass‑through)
“Sensor (250‑ and 550-sheet tray
pass‑through) removal” on page 507
4 41X1653 1 1 Right cover (optional
250-sheet tray)
“250‑ and 550-sheet tray right cover
removal” on page 498
4 41X1661 1 1 Right cover (optional
550-sheet tray)
“250‑ and 550-sheet tray right cover
removal” on page 498
5 41X1120 1 1 Paper size sensor
actuator
“250‑ and 550-sheet tray paper size
sensor actuator removal” on page 513
6 41X1108 1 1 Pick roller
“Pick roller removal” on page 503
7 41X1651 1 1 Front cover (250-sheet
tray insert)
“250‑ and 550-sheet tray insert front
cover removal” on page 502
7 41X2304 1 1 Front cover (550-sheet
tray insert)
“250‑ and 550-sheet tray insert front
cover removal” on page 502
8 40X7911 1 1 Sensor (paper size)
“Sensor (250‑ and 550-sheet tray paper
size) removal” on page 512
9 41X1656 1 1 Motor (transport)
“Motor (250‑ and 550-sheet tray
transport) removal” on page 504
10 41X1657 1 1 Controller board
(optional 250-sheet
tray)
“250‑ and 550-sheet tray controller
board removal” on page 506
10 41X2194 1 1 Controller board
(optional 550-sheet
tray)
“250‑ and 550-sheet tray controller
board removal” on page 506
11 41X1652 1 1 Left cover (optional
250-sheet tray)
“250‑ and 550-sheet tray left cover
removal” on page 496
11 41X1660 1 1 Left cover (optional
550-sheet tray)
“250‑ and 550-sheet tray left cover
removal” on page 496
12 41X1107 1 1 Paper feeder
“250‑ and 550-sheet tray paper feeder
removal” on page 504
13 41X1083 1 1 Sensor (paper present)
“Sensor (250‑ and 550-sheet tray paper
present) removal” on page 509
14 41X1083 1 1 Sensor (pick roller
index)
“Sensor (250‑ and 550-sheet tray pick
roller index) removal” on page 508
15 41X1654 1 1 Rear cover (optional
250-sheet tray)
“250‑ and 550-sheet tray rear cover
removal” on page 501
4064
Parts catalog
802

Lexmark MS823 Specifications

General

Print Technology	Monochrome Laser
Print Speed	Up to 65 ppm
Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 300, 000 pages
Recommended Monthly Page Volume	5, 000 - 75, 000 pages
Processor Speed	1 GHz
Standard Memory	512 MB
Connectivity	USB, Ethernet
Standard Input Capacity	650 pages
Maximum Paper Input	4, 400 sheets
Media Types Supported	Plain paper, Card stock, Envelopes, Labels, Transparencies
Operating System Compatibility	Windows, Linux
Duplex Printing	Automatic
