Lexmark MS823 Service Manual

Assembly 21: Output expander 1
Asm-index P/N Units/mach Units/FRU Description Removal procedure
140X8190 1 1Output expander left
cover
“Output expander left cover removal”
on page 522
2 40X8206 1 1 Output expander upper
interface cable
“Output expander upper interface
cable removal” on page 525
3 40X8205 1 1 Output expander lower
interface cable
“Output expander lower interface
cable removal” on page 525
440X8256 1 1Motor (OE diverter)
“Motor (OE diverter) removal” on
page 529
540X8721 2 1Output expander latch
“Output expander latch removal” on
page 528
6 40X8714 1 1 Motor (OE transport)
“Motor (OE transport) removal” on
page 532
740X8199 1 1Output expander
controller board
“Output expander controller board
removal” on page 524
8 40X7592 1 1 Sensor (OE rear door
interlock)
“Sensor (OE rear door interlock)
removal” on page 534
9 40X8726 1 1 Output expander drive
gear
“Output expander drive gear removal”
on page 531
10 40X8722 1 1 Output expander
diverter plunger
assembly
“Output expander diverter plunger
assembly removal” on page 529
11 40X7592 1 1 Sensor (OE diverter
plunger)
“Sensor (OE diverter plunger)
removal” on page 536
