Specications122
Table 7-18 Battery Run Time in Minutes Model: 10-kVA.Models
LOAD
INTERNAL
BATTERY
ONLY
NUMBER OF EXTERNAL BATTERY CABINETS
1 2 3 4 5 6 7 8 9 10
% VA W Minutes
10 1000 1000 59.0 129.0 211.0 294.0 377.0 460.0 543.0 625.5 708.5 791.5 874.5
20 2000 2000 25.0 62.5 99.0 136.0 179.5 222.5 266.0 309.5 353.0 396.5 439.5
30 3000 3000 14.5 38.5 63.5 88.0 113.0 138.5 168.0 197.0 226.5 256.0 285.5
40 4000 4000 9.5 26.0 45.0 64.0 82.5 101.0 120.0 139.5 161.5 183.5 206.0
50 5000 5000 7.0 19.0 33.5 49.0 64.0 79.0 94.0 109.0 124.0 140.0 158.0
60 6000 6000 5.5 14.5 26.0 39.0 51.5 64.5 77.0 89.5 102.0 114.5 127.0
70 7000 7000 4.0 12.0 21.0 31.5 42.5 54.0 64.5 75.0 86.0 97.0 107.5
80 8000 8000 3.5 9.5 17.5 26.5 36.0 45.5 55.5 64.5 74.0 83.5 93.0
90 9000 9000 2.5 8.0 15.0 22.5 30.5 39.5 48.0 56.5 65.0 73.0 81.5
100 10000 10000 2.0 7.0 13.0 19.5 26.5 34.5 42.0 50.0 57.5 65.0 72.5
Table 7-19 Battery Run Time in Minutes Model: 16-kVA.Models
LOAD
INTERNAL
BATTERY
ONLY
NUMBER OF EXTERNAL BATTERY CABINETS
1 2 3 4 5 6 7 8 9 10
% VA W Minutes
10 1600 1600 79.0 176.0 283.0 390.0 496.5 603.5 710.5 817.5 924.0 1031.0 1138.0
20 3200 3200 35.0 82.0 128.5 183.0 238.0 293.0 348.0 403.5 458.5 513.5 568.5
30 4800 4800 20.0 51.5 82.5 114.0 147.5 184.5 221.5 258.5 295.5 332.5 369.5
40 6400 6400 13.5 35.5 59.5 83.0 106.5 130.5 157.5 185.5 213.5 241.5 269.0
50 8000 8000 9.5 26.5 45.5 64.5 83.5 102.5 121.5 141.5 164.0 186.5 209.0
60 9600 9600 7.5 20.5 36.0 52.5 68.0 84.0 100.0 115.5 131.5 150.0 168.5
70 11200 11200 6.0 16.5 29.5 43.5 57.5 71.0 84.5 98.0 112.0 125.5 140.5
80 12800 12800 5.0 14.0 24.5 36.5 49.0 61.0 73.0 85.0 97.0 109.0 121.0
90 14400 14400 4.0 11.5 21.0 31.0 42.0 53.0 63.5 74.5 85.0 95.5 106.5
100 16000 16000 3.5 10.0 18.0 27.0 36.5 46.5 56.5 66.0 75.5 85.0 94.5
