Page #25 background imageLoading...
Page #25 background image
MX32x32DVI-HDCP-Pro and HDMI-Pro
User’s Manual v1.0
Page 25/ 109
2.8.3. Maximal Cable length at inputs
The unit has an advanced built-in cable compensation circuit, which provides
automatic or manual cable length compensation. This circuit extends the maximum
usable cable length to even 50 meters using high quality 22AWG copper cable at
WUXGA 1920x1200 graphics resolution.
Cable type
Signal
22 AWG
Reference type
DVI GEAR: SHR DVI
24 AWG
Reference type
TASKER: TSK 1060
Resolutions at 24 bits/pixel Max length (meter) Max length (meter)
1920x1200; 1600x1200;
2048x1080p; 1920x1080p
60 m 50 m
1680x1050; 1400x1050;
1280x1024
75 m 62 m
1024x768; 1365x768;
1280x720p; 1920x1080i;
92 m 77 m
800x600
100 m 84 m
640x480; 480p; 576p
120 m 100 m
Maximum DVI or HDMI cable lengths at inputs
The maximum cable lengths at the inputs of the MX-HDMI-TP-IB are shown below:
Resolution Cat5e UTP Cat5e FTP CAT6 UTP CAT6 FTP
CAT6 SFTP
CAT7 SFTP
640x480@60
60 m 60 m 65 m 70 m 70 m 80 m
800x600@60
60 m 60 m 65 m 65 m 65 m 75 m
1024x768@60
55 m 55 m 60 m 60 m 60 m 75 m
1280x720p60
55 m 55 m 60 m 60 m 60 m 70 m
1280x1024@60
50 m 50 m 55 m 60 m 60 m 65 m
1400x1050@60
45 m 45 m 45 m 55 m 55 m 60 m
1600x1200@60
30 m 35 m 35 m 45 m 45 m 50 m
1920x1080p60
30 m 35 m 35 m 45 m 45 m 50 m
1920x1200p60
30 m 35 m 35 m 45 m 45 m 50 m
Maximum UTP cable lengths at inputs
The above listed values were measured in 24 bits/pixel mode. The maximal cable
length in deep color modes will be shorter due to the higher data rate.
