MX32x32DVI-HDCP-Pro and HDMI-Pro
User’s Manual v1.0
Page 49/ 109
4.3. EDID router commands
4.3.1. Route EDID to the selected input (static)
Description: Copies EDID from location <loc>
to input <in>. <loc> must be 1..100
Example:
Note: (E_S_C) arrives only if the new and the old EDID don’t match.
4.3.2. Route EDID to the selected input (dynamic)
Description: It copies EDID from location <loc>
to input <in>. Location <loc> should be
101..132 as opposed to static routing where
<loc> should be between 1..100.
Info: Inputs 1..32 are mapped to logical addresses 101..132
After choosing dynamic EDID routing for one (or all inputs) the router will follow the
EDID changes that occur on the output it is connected to.
Example:
After issuing this command the router will automatically copy the new EDID on
output1 (remember logical address = 101) if it changes.
4.3.3. Route one EDID to all inputs
Description: It copies EDID from the selected
location <loc> to all inputs.
Example:
4.3.4. View EDID switch status on all inputs
Description: Indexes show the actual
input and the number at the given index
(<in1>..<inN>) shows which EDID is
switched to that particular input where N represents the maximal input number of
the given configuration.
Info: The length of <in1>..<inN> is always 3 digits! (001, 010, 100)
→ {<in>:<loc>}
← (E_SW_OK)CrLf
← (E_S_C) CrLf
→ {5:10}
← (E_SW_OK)CrLf
← (E_S_C) CrLf
→ {<in>:<loc>}
← (E_SW_OK)CrLf
← (E_S_C) CrLf
→ {4:101}
← (E_SW_OK)CrLf
← (E_S_C) CrLf
→ {A:<loc>}
← (E_SW_OK)CrLf
← (E_S_C) CrLf
→ {A:48}
← (E_SW_OK)CrLf
← (E_S_C) CrLf
→ {VEDID}
←
(VEDID●<in1>●<in2>●…●<inN>)CrLf
