MX32x32DVI-HDCP-Pro and HDMI-Pro
User’s Manual v1.0
Page 91/ 109
7.2. About Advanced EDID Management
The EDID router contains a 164-block non-volatile memory bank. EDID List is
structured as follows:
1..50 Factory Preset EDID list
51..100 User programmable memories
101..132 (OUT_1...32) Last attached monitor’s EDID list
133..164 (IN_1...32) Emulated EDID at input connectors
All EDID (including factory preset; user programmable memories; EDID at other
inputs; and EDID at outputs) can be switched and emulated at any of the inputs
Info: The first 50 EDID (1…50 inclusive) are factory preprogrammed and cannot be
modified. These are the most commonly used resolutions.
Info: Lightware matrices can handle both 128 Byte EDID and 256 Byte extended EDID
structures.
Info: The attached monitor’s EDID is stored automatically, until a new monitor is
attached to that particular output. In case of powering off the unit, the last attached
monitor’s EDID remains in the non-volatile memory.
Info: All factory EDID contains CEA extension which states that the device is HDMI
compliant and supports deep color modes. This allows the sources to send HDMI
signal if they are capable of it. The matrix is able to convert HDMI signals back to
DVI on the output ports if you have DVI capable display devices.
MEMORY Resolution MEMORY Resolution
01 640x480@60 Hz 26 1600x1200@50 Hz
02 640x480@75 Hz 27 1600x1200@60 Hz
03 848x480@60 Hz
28 1920x1200@60 Hz
04 800x600@50 Hz 29 1920x1200@50 Hz
05 800x600@60 Hz 30 480i@60 Hz
06 800x600@75 Hz 31 640x480@59.94 Hz
07 1024x768@50 Hz 32 720x480p@60 Hz
08 1024x768@60 Hz 33 576i@50 Hz
09 1024x768@75 Hz 34 720x576p@50 Hz
10 1152x864@75 Hz 35 1280x720p@50 Hz
11 1280x768@50 Hz 36 1280x720p@60 Hz
12 1280x768@60 Hz 37 1920x1080i1@50 Hz
13 1280x768@75 Hz 38 1920x1080i2@50 Hz
14 1360x768@60 Hz 39 1920x1080i@60 Hz
15 1364x768@50 Hz 40 1920x1080p@24 Hz
16 1364x768@60 Hz 41 1920x1080p@25 Hz
17 1364x768@75 Hz 42 1920x1080p@30 Hz
18 1280x1024@50 Hz 43 1920x1080p1@50 Hz
19 1280x1024@60 Hz 44 1920x1080p2@50 Hz
20 1280x1024@75 Hz 45 1920x1080p@60 Hz
21 1366x1024@60 Hz 46 2048x1080p1@50 Hz
22 1400x1050@50 Hz 47 2048x1080p2@50 Hz
23 1400x1050@60 Hz 48 2048x1080p@60 Hz
24 1400x1050@75 Hz 49 Universal EDID
25 1680x1050@60 Hz 50 2560x1600p@60 Hz
