Lightware MX8x8HDMI-PRO User Manual

MX32x32DVI-HDCP-Pro and HDMI-Pro
User’s Manual v1.0
Page 55/ 109
4.5. Input and output port status
4.5.1. Check the status of the inputs
Description: Use this command to
determine the actual status of the input ports.
Example:
Legend:
0
PWR5V signal is not present on this input.
1
PWR5V signal is present on this input.
2
Active DVI video signal is present on this input (data enable signal is
successfully recovered from the TMDS stream) but there is no PWR5V.
3
Active DVI video signal is present on this input (Data enable signal is
successfully recovered from the TMDS stream) with PWR5V.
6
The input port operates in HDMI mode but there is no PWR5V.
7
The input port operates in HDMI mode.
4, 5,
8
Not used
4.5.2. Check the status of the outputs
Description: Use this command to determine
the actual status of the output ports.
Example:
Legend:
0
There is no attached monitor
1
There is an attached monitor
→
{:ISD}
←
(ISD ● STATUS_TABLE)CrLf
MX32x32
→ {:ISD}
←
(ISD 0011233323330003
3330022000000000)CrLf
MX16
x16
→ {:ISD}
←
(ISD 0011733373330003)CrLf
MX8x8
→ {:ISD}
←
(ISD 07711303)CrLf
→
{:OSD}
←
(OSD●STATUS_TABLE)CrLf
MX32x32
→
{:OSD}
←
(OSD 0011011100110001
1100011000000000)CrLf
MX16x16
→
{:OSD}
←
(OSD
0011110111010001)CrLf
MX8x8
→
{:OSD}
←
(OSD 01011101)CrLf
