MX32x32DVI-HDCP-Pro and HDMI-Pro
User’s Manual v1.0
Page 43/ 109
4.1.10. Save preset to the specified memory location
Description: Save current ties to preset zz.
Example: Save current connections to preset
memory 7.
Info: The router saves the mute state of the outputs as well.
Info: Lock states are not saved. Lock state is assigned to the physical output of the
router. Presets don’t affect output locks.
4.1.11. Load preset from the specified location
Description: Load preset zz.
.
Example: Load connections previously saved to
preset memory 7. All connections will be reloaded.
Info: The router loads the mute state of the outputs as well.
Info: Lock states are not loaded. Lock state is assigned to the physical output of the
router. Presets don’t affect output locks.
4.1.12. View preset without loading
Description: View the specified preset
without loading it.
Examples:
4.1.13. Name Presets / Inputs / Outputs
Description: Allows storing names for
each preset / input / output. Any 16-
byte long string is allowed. All
characters are converted to uppercase!
The router accepts <id> greater than
the current I/O setup but treats it as modulo output. So if <id> = 9 on a 8x8 router,
then it will be treated as 1.
→ {$<id>}
← (SPR<id²>)CrLf
→ {$07}
